Pre-Packed Screen

Pre-packed Screen Pipe is the combination of screen with different diameter ,fill the quartz sand into the space between the double layers in the screen, to make the sand solid and close down, attain the result of defend the sand with sand. Quartz sand sizes and thickness of the  quartz sand layer can be Customized.

Features & Benefits
1. Extra strong resistance provided by the composite layer-dual screens and gravel
2. Wedged wire dual screens with high open area for a better well efficiency
3. The perfect gravel pack in shape, smoothness and permeability to optimize filtration
4. Work time less and more efficient

Applications
1. Commonly used in gas wells and gas storages and in cased or open-hole horizontal wells and also at the top of high pressure gravel pack completions
2. Excellent choice for preclusion the production of reservoir sand in wells
3. Suitable for marginal reservoirs requiring economical sand control options

Technical Data
Casing Size
(in)		 Outer Screen
OD (in.)		 Inner Screen
OD (in.)		 Base pipe
OD (in.)		 Base pipe
ID (in.)		 Coupling
OD (in.)
4 1/2 2.55 1.45 1.05 0.824 1.313
5 3.48 2.365 1.900 1.610 2.200
5 1/2 4.13 2.856 2.375 1.995 2.875
6 5/8 4.64 3.365 2.875 2.441 3.500
7 5.12 3.965 3.500 2.992 4.250
7 5/8 5.64 3.965 3.500 2.992 4.250
7 5/8 5.64 4.490 4.000 3.548 4.500
7 5/8 6.19 4.980 4.500 4.000 5.000
8 5/8 7.23 5.475 5.000 4.408 5.563
9 5/8 8.23 5.980 5.500 4.950 6.050
9 5/8 8.23 7.10 6.625 6.065 7.390
